Transend E+
$ 10.490.000
Marco : ALUXX aluminium, Double Diamond
Tenedor : ALUXX aluminium
Palancas de cambios : NEXUS 7 RevoShift, SL-C3000-7
Bielas : Giant Crank
Tenedor : ALUXX aluminium
Palancas de cambios : NEXUS 7 RevoShift, SL-C3000-7
Bielas : Giant Crank
A NEW WAY TO MOVE
Kick off a new commuting routine that’s adventurous, healthy and more fun than a train or a bus. Transend E+ is made with our SyncDrive Life motor and an integrated battery pack, giving you a seamless boost of pedaling power so you can ride farther and faster with less effort.
Geometría
| Talla del Marco | Rider Height | Standover Height |
|---|---|---|
| S | 160 cm to 173 cm | 72 cm |
| M | 170 cm to 180 cm | 76 cm |
| L | 178 cm to 193 cm | 81 cm |
| S | M | L | ||
|---|---|---|---|---|
| A | Seat Tube Length (mm) (inch) | 40015,7 | 47018,5 | 54521,5 |
| B | Seat Tube Angle (degrees) | 73,0° | 73,0° | 73,0° |
| C | Top Tube Length (mm) (inch) | 56522,2 | 58022,8 | 61524,2 |
| D | Head Tube Length (mm) (inch) | 1405,5 | 1505,9 | 1656,5 |
| E | Head Tube Angle (degrees) | 69,5° | 69,5° | 69,5° |
| F | Fork Rake (mm) (inch) | 502 | 502 | 502 |
| H | Wheelbase (mm) (inch) | 111744 | 113244,6 | 116846 |
| I | Chain Stay Length (mm) (inch) | 48519,1 | 48519,1 | 48519,1 |
| J | Bottom Bracket Drop (mm) (inch) | 602,4 | 602,4 | 602,4 |
| K | Stack (mm) (inch) | 58122,9 | 59023,2 | 60523,8 |
| L | Reach (mm) (inch) | 39315,5 | 40515,9 | 43617,2 |
| M | Stand Over Height (mm) (inch) | 71228 | 75829,8 | 80931,9 |
| N | Ancho de Manubrio (mm) (inch) | 72028,3 | 72028,3 | 72028,3 |
| O | Largo de espiga (mm) (inch) | 602,4 | 602,4 | 803,1 |
| Q | Tamaño de rueda | 27.5 | 27.5 | 27.5 |
Todas las especificaciones anteriores están sujetas a cambios sin previo aviso.
Imagen de referencia.
