Specs

Specifications

  • Sizes
    Small, Regular, Large
  • Colors
    Matte Asphant Black / Reflective, Brick Red / Reflective
  • Frame
    LUXX-grade aluminum
  • Fork
    ALUXX-grade aluminum rigid fork
  • Handlebar
    Giant Connect Trail, 31.8mm
  • Stem
    Giant Sport, 10 Degree
  • Seatpost
    Giant Alloy, 30.9mm
  • Saddle
    Comfort MTB
  • Pedals
    Nylon Anti-slip
  • Shifters
    N/A
  • Front Derailleur
    N/A
  • Rear Derailleur
    N/A
  • Brakes
    Tektro HDC-M275, [F]160mm rotor [R]160mm rotor, Hydraulic Disc
  • Brake Levers
    Tektro HDC-M275
  • Cassette
    22t
  • Chain
    Belt drive
  • Crankset
    Alloy, FOrged, 52t
  • Bottom Bracket
    Sealed Cartridge
  • Rims
    GIANT GX06, 27.5”, 6061 Aluminum, Double Wall
  • Hubs
    [F] Alloy, Sealed Bearing 32h ; [R] Alloy, Sealed Bearing 32h
  • Spokes
    Stainless 14G
  • Tires
    CST Quicksand
  • Weight
    The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Download PDF

The specifications, colors, and availability of the products can be subjects to alter without prior notification. For availability and prices, please contact the retailers in your city / country.

Geometry

Frame SizeRider HeightStandover Height
Small155 cm to 170 cm78 cm
Regular165 cm to 180 cm81 cm
Large175 cm to 190 cm83 cm

Momentum Framesize

  SmallRegularLarge
BSeat Tube Angle (degrees)73.0°73.0°73.0°
CTop Tube Length (mm) (inch)57022.459023.261024
DHead Tube Length (mm) (inch)1405.51606.31807.1
EHead Tube Angle (degrees)71.0°71.0°71.0°
HWheelbase (mm) (inch)106441.9108542.7110643.5
IChain Stay Length (mm) (inch)44517.544517.544517.5
KStack (mm) (inch)57422.659323.361224.1
LReach (mm) (inch)39415.540916.142316.7
MStand Over Height (mm) (inch)77830.680331.682832.6
PCrank Length (mm) (inch)1706.71706.71756.9
bike diagram

The specifications, colors, and availability of the products can be subjects to alter without prior notification. For availability and prices, please contact the retailers in your city / country.
